120′ Wide Hoop Building
The 120′ wide truss hoop barn is a very wide clear span fabric tension building that is both economically and ecologically ideal for an amazing number of uses.
The fact that this is a clearspan building means that there are absolutely no interior barriers to any use you have for this wide truss building.
High side walls add even more versatility with additional height which allows you to use every square foot of floorspace.
That is only part of why there is great potential for this hoop structure as an event or indoor sports center. There is also great light transmission during daylight hours and they can easily be artificially lighted at other times. How many soccer fields could you put in one of these? The size just boggles your mind!
We think this building would be great for livestock. Pens could be configured any way you need them and there is plenty of room for feed alleys. It could be a livestock mansion!
Imagine a riding arena where you could also house your horses. There are many ventilation and end options for the 120′ building, just as there are with all of our hoop structures.
We ask that you call us about this building because there are many options and alternatives to consider. We have years of experience to guide you to the clear span building you need.
Interested in this building?
888-497-1088
Specifications
- Available almost any length you want
- Roll-up fabric doors and door headers up to 16′
- End walls with supports.
- Colors, stripes, colors and more colors!
The 120′ clearspan building is a welded truss engineered building. It is a fabric tension building with a different shape than our smaller buildings. We call these our gable end buildings.
It is a clear-span building and can be constructed to meet or exceed IBC Engineering code requirements for a 90 mile-per-hour wind load and a 50 pound per square foot snow load. It is available with truss spacing at 10, 12 or 14 feet.
We don’t have a picture of this fabric barn because we haven’t built one this size yet but we’re looking forward to it. If you’re in our area and you need immense, unfettered space for any purpose, click here to give us a call. We’d love to work with you.
| Width | 118′ Interior width from wall to wall |
| Peak Height | 43’8″ plus height of wall |
| Tensioning System | Pipe with 2″ ratchets at each rafter and end |
| Cover Material | Tear resistant high-density polyethylene |
| Cover Weight | 12.5 oz. |
| Rafter Material | Welded Steel Trusses |
| Pipe Diameter | 4″ 8 ga top and bottom chords |
| Rafter Spacing | 10′ standard, 8′, 12′, 14′ and custom available |
| Cover Material Warranty | 15 year |
| Included | All hardware and lag bolts for post attachment |
| Not Included | Posts or walls, rub rail, baseboards or concrete anchors, assembly |
| Downloadable Specs | Click Here to Download PDF |
